Notes

Warning Binding the lazyload_event to 'scroll' may cause excessive lag.

  • This widget, added in v2.24.0, integrates the popular jQuery lazyload plugin & jQuery scrollstop.
  • This widget will only work if:
    • The image class, set by the lazyload_imageClass option is included.
    • The image width & height attributes are set.
    • The url to the image is added to the data-attribute, set by the lazyload_data_attribute option, and not the image src attribute.
    <img class="lazy" data-original="images/logo.png" width="300" height="300">
  • The images will load only if:
    • The image is inside the viewport.
    • When the user has stoped scrolling; this is because the lazyload_event option is set by default to use the "scrollstop" event, which is added by the jQuery scrollstop plugin (see lazyload_event option for more details).
  • In this demo, scroll down the page to see the lazyload plugin in action.
  • This widget will not work with the original tablesorter plugin (v2.0.5).

Options

Lazyload widget default options (added inside of tablesorter widgetOptions)

TIP! Click on the link in the option column to reveal full details (or toggle|show|hide all) or double click to update the browser location.
OptionDefaultDescription
Lazyload widget options
'lazy' This option contains the image class name targeted by the lazyload widget.

This option is set up to add a period to the beginning of this option, to make a jQuery class name selector.
'lazyloadUpdate' This option sets the event name that can be triggered to update the lazy load on newly loaded images.

This widget will work with the pager and columnSelector widget, so you shouldn't need to trigger this event, but you may need to use it if new rows are added or a cell with an image is updated.
jQuery scrollstop plugin option
250 Latency is the minimum time (in milliseconds) between the last scroll event and when the scrollstop event fires.

For more details, see the main plugin page.
jQuery lazyload plugin options
0 By default images are loaded when they appear on the screen.

If you want images to load earlier use threshold parameter. Setting threshold to 200 causes image to load 200 pixels before it appears on viewport.

For more details, see the main documentation.
0 Setting failure_limit to 10 causes plugin to stop searching for images to load after finding 10 images below the fold.

If you have a funky layout set this number to something high. Worst case being the actual number of images.

For more details, see the main documentation.
'scrollstop' Event to trigger image loading.

In the original plugin, the default for this option is 'scroll'. It was changed to 'scrollstop' in this widget to only load images after scrolling stops.

Alternative settings include 'click' (user clicks on image to load it) or 'mouseover'.

If this option is not set to 'scrollstop', then the scrollstop plugin will not be initialized.

Warning If the option is set to 'scroll', the plugin may cause excessive lag.

For more details, see the main documentation.
'show' By default plugin waits for image to fully load and calls show().

You can use any effect you want, e.g. 'fadeIn' effect.

For more details, see the main documentation.
window You can also use plugin for images inside scrolling container, such as div with scrollbar.

Just pass the container as jQuery object.

For more details, see the main documentation.
'original' You must alter your image tags. Address of the image must be put into data-original attribute.

Use this option to set a different attribute.

If you have a higher quality image that you want to load under certain conditions, use the lazyload_appear callback to change this setting. Here is an example that switches to load retina images:
$(function() {
	$( 'table' ).tablesorter({
		theme : 'blue',
		widgets : [ 'lazyload' ],
		widgetOptions : {
			lazyload_appear : function( elements_left, settings ) {
				// elements_left = number of images left to load
				// settings = lazyload plugin settings; not the widgetOptions setting which don't matter at this point
				settings.data_attribute = window.devicePixelRatio > 1 && $( this ).attr( 'retina' ) ?
					// use "data-retina" for higher resolution images
					'retina' :
					// fallback to "data-original" for non-retina displays
					'original';
			}
		}
	});
});
For more details, see the main documentation.
true There are cases when you have images which are in viewport but not :visible (v2.25.6).

In v2.25.6, change this default value to true to better work with the filter widget.

To improve performance you can ignore .not(":visible") images by setting this option to true.

For more details, see the main documentation.
null This function is called when image appears in the viewport, but before it is loaded.

Use this callback function as follows:

$(function() {
	$( 'table' ).tablesorter({
		theme : 'blue',
		widgets : [ 'lazyload' ],
		widgetOptions : {
			lazyload_appear : function( elements_left, settings ) {
				// elements_left = number of images left to load
				// settings = plugin settings; not the widgetOptions
				$( this ).parent().addClass( 'loading' );
			}
		}
	});
});
There doesn't appear to be any documentation for this callback in the main documentation.
null This function is called after the image has completed loading.

Use this callback function as follows:

$(function() {
	$( 'table' ).tablesorter({
		theme : 'blue',
		widgets : [ 'lazyload' ],
		widgetOptions : {
			lazyload_load : function( elements_left, settings ) {
				// elements_left = number of images left to load
				// settings = plugin settings; not the widgetOptions
				$( this ).parent().removeClass( 'loading' );
			}
		}
	});
});
There doesn't appear to be any documentation for this callback in the main documentation.
See description This placeholder replaces the image until it gets loaded.

By default, this setting is an encoded gif of a 1x1 transparent pixel.


For more details, see the main documentation.

Method

Force lazyload widget update

If you need to programmically force the lazyload widget to update, trigger a 'lazyloadUpdate' event on the table:
$( 'table' ).trigger( 'lazyloadUpdate' );
You can change this event name by setting the lazyload_update option.

Demo

First Name Last Name Image
BillMurrayMurray
JoyceYoungRed
JohnHoodGrey
ClarkKentBear
BeverlyPyleBlue
BruceAlmightyRandom
BillyMurrayMurray
FrankBedlamBlue
HarrySallyBear

Javascript




HTML
